EU Product - AudioCodes MediaPack 118 gateway/controller
Introduction
AudioCodes' MediaPack 1xx series of Analog VoIP Gateways are cost-effective, stand-alone VoIP gateways that provide superior voice technology for connecting legacy telephones, fax machines and PBX systems with IP telephony networks and IP-based PBX systems. The MediaPack 1xx series gateways support a wide variety of service provider and enterprise applications.
Specifications
| Protocols | |
|---|---|
| Management protocols | BootP, DHCP, TFTP, HTTP, DHCP, EMS, SNMP V3 |
| Security | |
| Security algorithms | HTTPS,SRTP,SSL/TLS |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Weight & dimensions | |
| Weight | 500 g |
| Dimensions (WxDxH) | 172 x 220 x 42 mm |
| Power | |
| Input voltage | 100 - 240 V |
| Input frequency | 500 Hz |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 40 °C |
| Storage temperature (T-T) | -20 - 85 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Technical details | |
| Interface | 4 x FXO, 4 x FXS |
| Voice codecs | G.711,G.722,G.723.1,G.726,G.729A,G.729B |
| Size | 48.3 cm (19") |
| AC adapter included | Yes |
| Indication | |
| LED indicators | Yes |
| Certificates | |
| Safety | EN60950-1 |
| Certification | EN55022 , CFR, EN55024, EN61000-3-3, EN61000-3-2, VCCI Class X1 |
| Design | |
| Mounting type | Rack mounting |
