EU Product - LevelOne IPCam Dome Fix Out 8MP/H.265/IR/ 9W/PoE/IP67
Introduction
The LevelOne FCS-3096 Fixed Dome Outdoor Camera offers a highly reliable, cost-effective outdoor IP surveillance solution in a low-profile dome mounted casing, which is rated at IP67 and able to withstand outdoor operating conditions such as rain, snow, extreme heat, dust and humidity. The FCS-3096 offers 8-Megapixel resolution, and with 802.3af standard PoE, can use a single Cat.5 cable to run both power and data, making deployments easy and flexible. The dome mounting prevents malicious tampering with the camera, making it a secure and smart choice for all outdoor installations.
Specifications
| Performance | |
|---|---|
| Infrared (IR) cut-off filter | Yes |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Dynamic range | 120 dB |
| Design | |
| Weatherproof | Yes |
| Country of origin | China |
| IK code | IK10 |
| Form factor | Dome |
| Product colour | White |
| Mounting type | Ceiling |
| Protection features | Vandal proof |
| LED indicators | Power |
| International Protection (IP) code | IP67 |
| Camera | |
| Field of view (FOV) angle | 79° |
| Camera shutter speed | 1/3 - 1/10000 s |
| Progressive scan | Yes |
| Image sensor | |
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.5 mm (1 / 2.5") |
| Lens system | |
| Number of lenses | 1 |
| Maximum aperture number | 2 |
| Zoom capability | Yes |
| Lens diameter | 4 mm |
| Night vision | |
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | IR |
| Video | |
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Noise reduction technology | 3D noise reduction |
| Video compression formats | H.264, H.265, M-JPEG |
| Maximum resolution | 3840 x 2160 pixels |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 2560 x 1920, 3840 x 2160 |
| Frame rate | 30 fps |
| Total megapixels | 8 MP |
| Audio | |
| Voice codecs | G.711, G.722.1, G.726, MP2L2 |
| Audio system | 2-way |
| Network | |
| Bluetooth | No |
| Networking standards | IEEE 802.3af |
| Quality of Service (QoS) support | Yes |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
| Storage | |
| Maximum memory card size | 128 GB |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Ports & interfaces | |
| Terminal block port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Management features | |
| Web-based management | Yes |
| Power | |
| Power source type | DC, PoE |
| Power consumption (max) | 9 W |
| Power consumption (typical) | 6.2 W |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | 0 - 95 °C |
| Weight & dimensions | |
| Package type | Box |
| Width | 111 mm |
| Depth | 111 mm |
| Height | 82 mm |
| Weight | 500 g |
| Package width | 134 mm |
| Package height | 108 mm |
| Package depth | 134 mm |
| Packaging data | |
| Package type | Box |
| Package width | 134 mm |
| Package height | 108 mm |
| Package depth | 134 mm |
| Sustainability | |
| Sustainability compliance | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS, WEEE |
| Packaging content | |
| Number of cameras | 1 |
| Screws included | Yes |
| Package type | Box |
| Resource CD | Yes |
| Manual | Yes |
| Technical details | |
| Pallet gross width | 120 cm |
| Pallet gross length | 80 cm |
| Pallet height (air) | 162 cm |
| Master (outer) cases per pallet (air) | 20 pc(s) |
| Sustainability compliance | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS, WEEE |
| Other features | |
| Video compression formats | H.264, H.265, M-JPEG |
| Logistics data | |
| Master (outer) case width | 345 mm |
| Master (outer) case length | 590 mm |
| Master (outer) case height | 568 mm |
| Master (outer) case gross weight | 17 kg |
| Products per master (outer) case | 24 pc(s) |
| Pallet gross width | 120 cm |
| Pallet gross length | 80 cm |
| Pallet height (air) | 162 cm |
| Master (outer) cases per pallet (air) | 20 pc(s) |
| Harmonized System (HS) code | 8525890000 |
