EU Product - LevelOne Switch 5xGE unmanaged Plastik
Introduction
The LevelOne GEU-0522 is a wire-speed, non-blocking networking device that provides 5 ports 10/100/1000Mbps Ethernet connections. All ports support auto-negotiation and auto-MDI/MDIX sensing, eliminating the need for crossover cables or Uplink Ports. Each port can be used as general network port or as connecting port into a router, server, hub or another network switch.
Specifications
| Ports & interfaces | |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-T, 1000BASE-T |
| Network | |
| MAC address auto-learning supported | Yes |
| MAC address auto-aging supported | Yes |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-T, 1000BASE-T |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| 10G support | No |
| Auto-negotiation | Yes |
| Data transmission | |
| Packet forwarding rate (100 Mbps) | 148810 pps |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Packet forwarding rate (1 Gbps) | 1488100 pps |
| Jumbo frames | 9000 |
| MAC address table | 1000 entries |
| Switching capacity | 10 Gbit/s |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Design | |
| Product colour | Black |
| Stackable | No |
| LED indicators | Activity, Link, Power |
| Country of origin | China |
| Certification | CE, FCC |
| Performance | |
| Buffer size | 64 KB |
| Stackable | No |
| Auto-negotiation | Yes |
| Harmonized System (HS) code | 85176990 |
| Power | |
| Input voltage | 5 V |
| Input current | 0.6 A |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 86 mm |
| Depth | 23 mm |
| Height | 89 mm |
| Weight | 71.4 g |
| Packaging content | |
| Quick start guide | Yes |
| AC adapter included | Yes |
| Packaging data | |
| AC adapter included | Yes |
| Package type | Box |
| Package width | 95 mm |
| Package depth | 82 mm |
| Package height | 98 mm |
| Package weight | 184 g |
| Quick start guide | Yes |
| Technical details | |
| Product colour | Black |
| Stackable | No |
| Certificates | |
| Certification | CE, FCC |
| Indication | |
| LED indicators | Activity, Link, Power |
| Other features | |
| Input voltage | 5 V |
| Country of origin | China |
| Logistics data | |
| Country of origin | China |
| Master (outer) case width | 495 mm |
| Master (outer) case length | 191 mm |
| Master (outer) case height | 516 mm |
| Master (outer) case gross weight | 10.2 kg |
| Products per master (outer) case | 50 pc(s) |
| Harmonized System (HS) code | 85176990 |
