EU Product - WL-Repeater RE335 AC1200
Introduction
TP-Link RE335. Maximum data transfer rate: 867 Mbit/s. Antenna design: Internal. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 867 Mbit/s. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3u. Connectivity technology: Wired & Wireless
Specifications
| Data transmission | |
|---|---|
| Maximum data transfer rate | 867 Mbit/s |
| Antenna | |
| Antennas quantity | 2 |
| Antenna design | Internal |
| Wireless LAN features | |
| Signal strength | 30 dBm |
| Receiver sensitivity | 5 GHz: 11a 6Mbps: -94dBm, 11a 54Mbps: -77dBm 11ac HT20 MCS0: -94dBm, 11ac HT20 MCS8: -71dBm 11ac HT40 MCS0: -92dBm, 11ac HT40 MCS9: -66dBm 11ac HT80 MCS0: -87dBm, 11ac HT80 MCS9: -62dBm 2.4 GHz: 11g 54Mbps: -78dBm, 11n HT20 MCS7: -76dBm 11n HT40 MCS7: -74dBm |
| Wi-Fi | Yes |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) | 867 Mbit/s |
| Network | |
| Networking standards | IEEE 802.3, IEEE 802.3u |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Ethernet LAN interface type | Fast Ethernet |
| Ports & interfaces | |
| Ethernet LAN | Yes |
| Connectivity technology | Wired & Wireless |
| Ethernet LAN (RJ-45) ports | 1 |
| Security | |
| WPS push button | Yes |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK |
| Features | |
| Product type | Network repeater |
| Product colour | White |
| Reset button | Yes |
| Power LED | Yes |
| LED indicators | Yes |
| System requirements | |
| Compatible operating systems | Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX, Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (max) | 9.5 W |
| Power source type | AC |
| Power consumption (typical) | 9.5 W |
| Management features | |
| LED indicators | Yes |
| Certificates | |
| Certification | FCC, RoHS |
| Compliance certificates | CE, RoHS |
| Technical details | |
| Product colour | White |
| Quantity per pack | 1 pc(s) |
| Compliance certificates | CE, RoHS |
| Weight & dimensions | |
| Width | 69.5 mm |
| Depth | 35 mm |
| Height | 124.1 mm |
| Indication | |
| Power LED | Yes |
| Packaging content | |
| Quick installation guide | Yes |
| Packaging data | |
| Package width | 167 mm |
| Package weight | 200 g |
| Package type | Box |
| Package height | 90 mm |
| Package depth | 106 mm |
| Quantity per pack | 1 pc(s) |
