EU Product - LT300 Wi-Fi 4G LTE Cat4 Router - Router - WLAN
Introduction
Compact Design with Full Connectivity
Connect via Wireless and Ethernet
Insert a Nano SIM and enjoy flawless Internet via Wi-Fi and two 10/100 Mbps Ethernet Ports.
Keep Connected with Network Failover
The WAN/LAN port allows you to use broadband as the primary network, back it up with WISP and Cellular, keeping your internet always online.
Easy Setup, Versatile Management
Network Status Panel
Finish setup in minutes and know the system status at a glance with the status panel.
Parental Controls
Create profiles to block certain pages and limit online time such as weekday or weekends to protect your loved ones.
VPN Client and Servers
PPTP/L2TP/WireGuard/OpenVPN allow you to connect multiple devices at once to your private or commercial VPN.
Enhanced Security
WPA3 encrypts your wireless communication and protects your data from leaking.
Plug in a SIM Card to Enjoy the Network
Home
Plug and play easy-to-install WiFi for every home—no rigid broadband subscription is required.
Automobile
Provide decent networks for all devices on your road journey.
Surveillance
Make sure the network is always on with the WAN + WISP + 4G backup function.
Booth
Utilized the flexible pay-as-you-go plan to equip your temporary booth with a fast network. (SIM card is not included).
Specifications
| Ethernet LAN features | |
|---|---|
| Ethernet WAN | Yes |
| Ethernet LAN interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| DSL features | |
| DSL WAN | No |
| Mobile network | |
| SIM card slot | Yes |
| 3G/4G USB modem compatibility | No |
| Mobile network generation | 4G |
| 3G standards | WCDMA |
| 4G standard | LTE-TDD & LTE-FDD |
| 4G LTE category | 4 |
| SIM card type | NanoSIM |
| Network | |
| Guest access | Yes |
| Ethernet LAN interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Port forwarding | Yes |
| Port triggering | Yes |
| Number of guest networks (2.4 GHz) | 1 |
| Protocols | |
| DMZ support | Yes |
| Universal Plug and Play (UPnP) | Yes |
| DHCP server | Yes |
| DHCP client | Yes |
| Management features | |
| Universal Plug and Play (UPnP) | Yes |
| WPS push button | Yes |
| Web-based management | Yes |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| MIMO | Yes |
| Performance | |
| Processor frequency | 580 MHz |
| Processor cores | 1 |
| Built-in processor | Yes |
| Internal memory | 64 MB |
| Flash memory | 8 MB |
| Weight & dimensions | |
| Package width | 176 mm |
| Package weight | 366.5 g |
| Package height | 56 mm |
| Package depth | 140.5 mm |
| Width | 118 mm |
| Weight | 172.2 g |
| Height | 27.5 mm |
| Depth | 80 mm |
| WAN connection | |
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | Yes |
| 3G/4G USB modem compatibility | No |
| WAN connection type | RJ-45 |
| Wireless LAN features | |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max) | 300 Mbit/s |
| Wi-Fi band | Single-band (2.4 GHz) |
| WLAN data transfer rate (first band) | 300 Mbit/s |
| Wi-Fi standards | 802.11g, 802.11b, Wi-Fi 4 (802.11n) |
| Ports & interfaces | |
| USB port | No |
| Ethernet LAN (RJ-45) ports | 2 |
| DC-in jack | Yes |
| Security | |
| URL filtering | Yes |
| Security algorithms | WPA, WPA2, WPA3 |
| MAC address filtering | Yes |
| IP address filtering | Yes |
| Guest access | Yes |
| Firewall | Yes |
| DMZ support | Yes |
| Filtering | Yes |
| IGMP snooping | Yes |
| Design | |
| Product type | Tabletop router |
| LED indicators | LTE, System |
| Product colour | White |
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Packaging content | |
| Cables included | LAN (RJ-45) |
| AC adapter included | Yes |
| Quick installation guide | Yes |
| Other features | |
| Internal memory | 64 MB |
| Flash memory | 8 MB |
| Antenna | |
| Antenna design | Internal & external |
| Antennas quantity | 4 |
| Antenna gain level (max) | 2.83 dBi |
| Antenna type | 2x2 |
| Features | |
| Processor frequency | 580 MHz |
| Processor cores | 1 |
| Built-in processor | Yes |
| Internal memory | 64 MB |
| Flash memory | 8 MB |
| Power | |
| Power source type | DC |
| Output voltage | 12 V |
| Output current | 1 A |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Packaging data | |
| Package width | 176 mm |
| Package weight | 366.5 g |
| Package height | 56 mm |
| Package depth | 140.5 mm |
| Cables included | LAN (RJ-45) |
| AC adapter included | Yes |
| Quick installation guide | Yes |
| Technical details | |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
