EU Product - Barcodescanner Industrie CCD USB schwarz
Introduction
Improve speed, accuracy and productivity._x000D_
_x000D_
_x000D_
Manhattan Linear CCD Barcode Scanners deliver high-quality scanning for a wide range of data collection functions to help improve routine transactions, automate paper-based processes and increase productivity. The CCD (charged-coupled device) scan engine features no moving parts, and has a rugged impact-resistant housing for years of reliable service of reading popular barcodes, including UPC, EAN, ASCII and GS1 DataBar. Easy to implement and simple to use, a built-in keyboard wedge decoder sends scanned data to an active application, where it appears as if it were manually typed or directly keyed into the computer. With a scan rate of 500 scans per second and an accurate read range of up to 500 mm (20 in.), this model offers a high-performance, all-purpose daily scanning solution for point-of-sale, shipping, warehousing, office and industrial applications to minimize manual data entry, speed transactions and reduce errors.
Specifications
| Scanning | |
|---|---|
| Type | Handheld bar code reader |
| Linear (1D) barcodes supported | Code 11, Code 128, Code 32, Code 39, Code 93, GS1-128 (UCC/EAN-128), JAN |
| 2D (matrix & stacked) barcodes supported | Not supported |
| Working distance | 50 cm |
| Wavelength | 632 nm |
| Sensor type | CCD |
| Scanner type | 1D |
| Read rate (max) | 500 reads/s |
| Maximum scan width | 50 cm |
| Light levels (direct sunlight) | 0 - 10000 lx |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Standard interfaces | Keyboard wedge, RS-232, USB |
| Performance | |
| LED indicators | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS), Rubber |
| International Protection (IP) code | IP54 |
| Product colour | Black |
| Certification | FCC, CE, RoHS |
| Light levels (direct sunlight) | 0 - 10000 lx |
| Design | |
| Type | Handheld bar code reader |
| LED indicators | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS), Rubber |
| International Protection (IP) code | IP54 |
| Product colour | Black |
| Certification | FCC, CE, RoHS |
| Power | |
| Power consumption | 70 mA |
| Input voltage | 5 V |
| Weight & dimensions | |
| Width | 70 mm |
| Depth | 180 mm |
| Height | 70 mm |
| Weight | 150 g |
| Technical details | |
| Type | Handheld bar code reader |
| LED indicators | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS), Rubber |
| International Protection (IP) code | IP54 |
| Product colour | Black |
| Certification | FCC, CE, RoHS |
| Harmonized System (HS) code | 84716070 |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 20 - 95% |
| Light levels (direct sunlight) | 0 - 10000 lx |
| Logistics data | |
| Harmonized System (HS) code | 84716070 |
