THECUS N16000PRO THECUS Thecus N16000PRO NAS/storage server Rack (3U) Ethernet LAN E3-1275

*Image accuracy is not guaranteed. Please do not rely on the image for your purchase.. ** All heavy items above 25KG will be charged shipping cost as per actual. Please contact us for a shipping quote before placing order

N16000PRO THECUS Thecus N16000PRO NAS/storage server Rack (3U) Ethernet LAN E3-1275

Part No:N16000PRO

EAN Code:

price matchPrice Match
Guarantee
DeliveryExpeditious Delivery
customer satisfaction100% Customer
Satisfaction
secure paymentSecure Payment
Options
Accept Purchase orders
We accept Purchase Orders from Education Sector, Hospitals, Police, Councils and more.Choose Payment Option "Purchase Order" While placing your order online.

Any Questions?

If you have any questions about price and availability of the product, please drop us a query below:

Thecus N16000PRO NAS/storage server Rack (3U) Ethernet LAN E3-1275

Introduction

Better processors for better performance The new PRO series of 12 and 16-bay NAS comes with the fastest Intel® technology ever seen at Thecus®. The N16000PRO and the N12000PRO are equipped with the Xeon® E3-1275 processor that runs at 3.4 GHz. The quad-core processors are matched by 8GB of DDR3 RAM on both devices to make sure that the biggest commands fly through without an itch. And to make sure the full power of the processors is used, a 10GbE network card can be added to the available PCI-e slot and link aggregation can be used to make sure your network doesn't slow you down. Store big with Volume Expansion and Daisy Chaining Brought on by the ThecusOST 5.0, users can now dynamically stack their NAS units for more capacities in a single volume; simply designate your N16000PRO or N12000PRO as a stack master and implement a 10GbE switch to connect additional target devices. Scalability is the key notion when it boils down to volume expansion. In fact, an amazing eight target devices can be intertwined for a massive volume of multi TB capacity when utilizing 10GbE switch. Daisy-chaining is the most innovative function to expand storage volume while keeping cost down. Up to four D16000 DAS can be added to your N16000PRO and N12000PRO for an additional 64 bays of storage. As a result, IT enterprises or consumers who utilize large amounts of storage can obtain massive expansion and save cost. Another perk about daisy-chaining is that transfer speeds are fast! Thanks to the SAS cables that are put-to-use to daisy-chain the DAS to the NAS. If paired with volume expansion, daisy-chain can help large businesses expand their storage capacity to up to 2.5 PB! 10GBASE-T High Availability (HA) The N12000PRO and N16000PRO both run on ThecusOSTM 5.0 which supports one of the most important features within the storage industry, High Availability. In short, HA allows users to replicate the data on an active NAS to another standby NAS via 10GbE synchronization. The importance of HA is quickly noticeable, whether there is data corruption or if the active NAS has any HDD problems or downtime, the standby server keeps all vital data saved and is available at all time to take over the active NAS' responsibilities. Total backup solution Also supported by the N16000PRO and the N12000PRO is the total backup solution, Data Guard. This backup solution is the ultimate feature as it provides both local and remote backup under one roof. Currently, data is backed up across RAID volumes, external USB drives, and eSATA. In addition, Data Guard uses innovative technology to sync data across the network to other NAS, take advantage of real-time remote replication to keep your data safe. More importantly, Thecus® Data Guard is the total backup solution which makes managing NAS user-friendly and convenient. Additionally, to cover enterprises backup needs, Thecus® joined hands with Acronis and gives five free registered copies of their Backup & Recovery 10 Server for Windows. Acronis offers a wide range of critical features which includes scheduling and hot backups with password protection, advanced compression functionality to help save space, incremental backups to save time and FTP/SFTP remote backup. Windows Server users now have a seamless, practical and secure system disaster recovery solution with the features offer by Acronis Backup & Recovery 10 Server for Windows (OEM). Antivirus solution In a multiple users environment, it is easy to spread a virus or malware through the data stored on the NAS. Adding an antivirus to the already comprehensive software bundle will provide the necessary software protection by scanning the files on your NAS and defending it against possible threats. McAfee is the world's largest dedicated security technology company and shares Thecus' spirit of dedication and quality. By establishing a strong partnership with them, Thecus® allow users the benefit of McAfee's powerful software on their NAS entirely for free. Conclusion The N16000PRO and the N12000PRO from Thecus® are designed to meet the needs of large businesses with large amount of data and who expect professional performance out of their NAS. With unified storage, the users will have the ability to plug their NAS to an iSCSI network, and at the same time, use your Thecus® NAS as an IP Storage pool for both protocols. This way, the NAS can be compatible with any existing or future architecture. Now with faster processors, the N16000PRO and the N12000PRO will deliver quicker response time and handle multitasking with even better ease than before. The N16000PRO and the N12000PRO are a statement that Thecus® promises to always provide professional level NAS for all.

Specifications

Specifications


Storage
Number of storage drives supported16
Storage drive interfaceSerial ATA
RAID supportYes
Supported file systemsext3,ext4,XFS
RAID levels0,1,5,6,10,50,60,JBOD
Processor
Processor manufacturerIntel
Thermal Design Power (TDP)95 W
Tcase72.6 °C
System bus rate5 GT/s
SteppingD2
Processor threads8
Processor socketLGA 1155 (Socket H2)
Processor package size37.5 x 37.5 mm
Processor operating modes64-bit
Processor lithography32 nm
Processor codenameSandy Bridge
Processor codeSR00P
Processor cache typeSmart Cache
Processor cache8 MB
Processor boost frequency3.8 GHz
PCI Express slots version2.0
On-board graphics adapter modelIntel® HD Graphics P3000
ECC supported by processorYes
CPU multiplier (bus/core ratio)3.4
CPU configuration (max)1
Bus typeDMI
Maximum internal memory supported by processor32 GB
Memory bandwidth supported by processor (max)21 GB/s
Processor ARK ID52277
Processor frequency3.4 GHz
Processor familyIntel® Xeon® E3 Family
Processor modelE3-1275
Processor cores4
Number of processors installed1
L3 cache8 MB
Memory
Internal memory typeDDR3
Internal memory8 GB
Network
Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Wi-FiNo
iSCSI supportYes
Cabling technology10/100/1000Base-T(X)
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 2.0 ports quantity6
RS-232 ports1
HDMI ports quantity1
Ethernet LAN (RJ-45) ports3
eSATA ports quantity2
eSATAYes
Hard drive
RAID supportYes
Supported file systemsext3,ext4,XFS
RAID levels0,1,5,6,10,50,60,JBOD
Graphics
On-board graphics adapter modelIntel® HD Graphics P3000
On-board graphics adapter dynamic frequency (max)1350 MHz
On-board graphics adapter base frequency850 MHz
Number of displays supported (on-board graphics)2
Design
Display typeOLED
Chassis typeRack (3U)
Technical details
Display typeOLED
Multilingual supportYes
Chassis typeRack (3U)
Performance
Windows operating systems supportedYes
Mac operating systems supportedYes
Linux operating systems supportedYes
Security algorithms256-bit AES
Multilingual supportYes
Access Control List (ACL)Yes
Security
Security algorithms256-bit AES
Access Control List (ACL)Yes
Software
Windows operating systems supportedYes
Mac operating systems supportedYes
Linux operating systems supportedYes
Power
Power supply unit (PSU) capacity700 W
Redundant power supply (RPS) supportYes
Weight & dimensions
Width440 mm
Depth662 mm
Height133 mm
Processor special features
Thermal Monitoring TechnologiesYes
Maximum number of PCI Express lanes20
Intel® Wireless Display (Intel® WiDi)No
Intel® Turbo Boost Technology2.0
Intel® Smart CacheYes
Intel® Quick Sync Video TechnologyYes
Intel® InTruT 3D TechnologyYes
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Trusted Execution TechnologyYes
Intel Identity Protection Technology version1.00
Intel Flex Memory AccessYes
Intel FDI TechnologyYes
Intel Fast Memory AccessYes
Intel Enhanced Halt StateYes
Intel Dual Display Capable TechnologyYes
Intel Demand Based SwitchingYes
Intel 64Yes
Idle StatesYes
Execute Disable BitYes
Enhanced Intel SpeedStep TechnologyYes
Embedded options availableYes
Memory channels supported by processorDual
Memory types supported by processorDDR3-SDRAM
