EU Product - MC220 - - - 10. - Converter - 1 Gbps
Introduction
Instant Network Monitoring with Built-in LED Indicators
With built-in LED indicators, you can easily check the working status of the device. The network status is instantly visible, making it simple to monitor and troubleshoot at a glance.
Reliable, High-Speed Transmission with No Speed Loss
The all-in-one module delivers exceptional optical and electrical performance, ensuring long-term data transmission stability.
Plug and Play, No Setup Required
Simply plug in the port, and it’s ready to go—instant connection with no configuration needed. Easy to use, with fast and responsive performance.
Specifications
| Network | |
|---|---|
| Flow control support | Yes |
| Auto-negotiation | Yes |
| Cable types supported | Cat5, Cat5e |
| Copper ethernet cabling technology | 100BASE-TX, 100BASE-FX, 1000BASE-TX |
| Converter input interface | 1000Base-TX, 1000Base-FX |
| Networking standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Gigabit Ethernet |
| Auto MDI/MDI-X | Yes |
| Maximum data transfer rate | 1000 Mbit/s |
| Fiber optic connector | SFP |
| Performance | |
| Wavelength | 1310 nm |
| Maximum transfer distance | 20000 m |
| Fiber mode structure | Single-mode |
| Buffer size | 9 KB |
| Sensitivity | 24 dBmW |
| Mean time between failures (MTBF) | 50000 h |
| Flow control support | Yes |
| Auto-negotiation | Yes |
| Plug and Play | Yes |
| Features | |
| Plug and Play | Yes |
| LED indicators | Yes |
| Product colour | Black |
| Internal | No |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SFP |
| Power | |
| Input voltage | 90 - 240 V |
| Output voltage | 5 V |
| Power consumption (typical) | 4 W |
| AC input frequency | 50 - 60 Hz |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 60 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Technical details | |
| Wavelength | 1310 nm |
| Maximum transfer distance | 20000 m |
| Fiber mode structure | Single-mode |
| Buffer size | 9 KB |
| Sensitivity | 24 dBmW |
| Plug and Play | Yes |
| Internal | No |
| Indication | |
| LED indicators | Yes |
| Design | |
| LED indicators | Yes |
| Product colour | Black |
| Internal | No |
| Endurance | |
| Mean time between failures (MTBF) | 50000 h |
| Management features | |
| Plug and Play | Yes |
| Colour | |
| Product colour | Black |
