Pci-e Wireless-ac Card - Ac1200 Adapter 2.4 / 5GHz
Introduction
The PEX867WAC22 PCI Express AC1200 Wireless Network Adapter lets you add dual-band Wireless-AC connectivity to a desktop computer through a PCIe slot.
With increased demand on network resources, this Wireless-AC adapter gives you exceptional speed and range for your office or home wireless network when paired with an 802.11ac router. This dual-band WiFi adapter supports maximum data rates of up to 867 Mbps on the 5GHz band (3x the speed of Wireless-N), plus up to 300 Mbps on the 2.4GHz band, making it the perfect solution for applications like HD video streaming, online conferencing, file transfers and gaming.
This versatile PCIe wireless card features a 2T2R (2 transmitter, 2 receiver) detachable antenna design, with an included magnetic antenna stand that can easily be mounted to the top or side of your PC case. Plus, the controller card is equipped with a standard profile bracket and includes a low-profile/half-height bracket for installation in small form-factor computers. To integrate with all of your networking devices, the adapter is also backward compatible with 802.11a/b/g/n networks.
Backed by a StarTech.com 2-year warranty, with free lifetime technical support.
Benefits
- Experience faster wireless speed and better coverage with 802.11ac compatibility
- Ensure fast and dependable wireless networking, with less interference through dual band 2.4 GHz / 5 GHz operation
- Connect to existing wireless networks with 802.11a/b/g/n backward compatibility
Features
- Wireless AC1200 compatible (867 Mbps + 300 Mbps)
- Compliant with 802.11 a/b/g/n/ac standards
- Dual band 2.4 / 5 GHz support (802.11ac is 5 GHz only)
- PCI Express host interface
- 2 Transmitter/2 Receiver (2x2:2) antenna configuration
- Included magnetic antenna stand for side-mounting on your PC case
- Supports WEP (64-128-bit), WPA and WPA2 wireless security
- Supports WMM Quality of Service
- Supports Soft AP mode
- Configured with standard profile bracket, low profile/half-height bracket included
Specification
- Experience faster wireless speed and better coverage with 802.11ac compatibility
- Ensure fast and dependable wireless networking, with less interference through dual band 2.4 GHz / 5 GHz operation
- Connect to existing wireless networks with 802.11a/b/g/n backward compatibility
Features
- Wireless AC1200 compatible (867 Mbps + 300 Mbps)
- Compliant with 802.11 a/b/g/n/ac standards
- Dual band 2.4 / 5 GHz support (802.11ac is 5 GHz only)
- PCI Express host interface
- 2 Transmitter/2 Receiver (2x2:2) antenna configuration
- Included magnetic antenna stand for side-mounting on your PC case
- Supports WEP (64-128-bit), WPA and WPA2 wireless security
- Supports WMM Quality of Service
- Supports Soft AP mode
- Configured with standard profile bracket, low profile/half-height bracket included
Specification
- Wireless AC1200 compatible (867 Mbps + 300 Mbps)
- Compliant with 802.11 a/b/g/n/ac standards
- Dual band 2.4 / 5 GHz support (802.11ac is 5 GHz only)
- PCI Express host interface
- 2 Transmitter/2 Receiver (2x2:2) antenna configuration
- Included magnetic antenna stand for side-mounting on your PC case
- Supports WEP (64-128-bit), WPA and WPA2 wireless security
- Supports WMM Quality of Service
- Supports Soft AP mode
- Configured with standard profile bracket, low profile/half-height bracket included
Specification
Connector Type(s): PCI Express x1 Male
Wireless AC (IEEE 802.11ac)
External Ports: RP-SMA (Coax, Reverse Polarity SubMiniature A) Female
Operating Temperature: 0°C to 60°C (32°F to 140°F)
Storage Temperature: 0°C to 70°C (32°F to 158°F)
Humidity: 10~90% RH
Interface: Wireless Ethernet
Bus Type: PCI Express
Card Type: Standard Profile (LP bracket incl.)
Antenna Configuration: 2x2: 2 (TxR: S)
Industry Standards: IEEE 802.11ac Draft 2.0, IEEE 802.11n, IEEE 802.11g, IEEE 802.11a, IEEE 802.11b
Chipset ID: Realtek - RTL8812AE
LED Indicators: Link / Act
Shipping (Package) Weight: 388 g [13.7 oz]
Maximum Data Transfer Rate: 867 Mbps (5 GHz)
Full Duplex Support: Yes
Frequency Range: 2.400 ~ 2.484GHz
Security Features: WEP Data Encryption
WPA and WPA2-PSK Data Encryption
WPA and WPA2 Enterprise Data Encryption
TKIP/AES
Product Length: 87 mm [3.4 in]
Product Width: 18 mm [0.7 in]
Product Height: 120 mm [4.7 in]
Product Weight: 82 g [2.9 oz]
OS Compatibility: Windows XP, 7, 8, 8.1, 10
System and Cable Requirements: Available PCI Express x1 (or higher) slot
Included in Package: PCI Express Wireless AC Card
5 dBi Dual Band Antennas
Antenna Stand
Low Profile Bracket
Driver CD
Instruction Manual
