4k30 Hdmi USB Over Ip Controller
Introduction
This Controller can be used to manage the Lindy Encoder 38396 and Decoder 38397 that features HDMI, USB, IR, RS-232 and Audio signals.
It's possible to distribute all the signals through a 1G managed network switch and to set up many configurations and layouts such as Video Wall, matrix, drag & drop operations and image preview.
It has dual network ports, one for network control and one for multicast video distribution, and provides control via Web GUI, TCP, RS-232, IR & GPIO.
The convenient PoE gigabit interface allows users to install the unit without connecting the included PSU.
What's Included
- 4K30 HDMI & USB over IP Controller
- IR Receiver Cable, 1.5m
- 2 x Mounting Ears & 4 x Screws
- 3-Pin Terminal Block
- 6-Pin Terminal Block
- Multi-country Power Supply (UK, EU, US & AUS)
- Lindy Manual
Features
- Supports video, audio, RS-232, IR, KVM control and management of the distributed system
- Built-in Web GUI control interface, supporting Drag & Drop operations and image preview
- Support LAN/RS-232 port control and third-party central control
- Dual network ports to isolate Controls and Multicast networks
Specifications
- Supported Bandwidth: 1Gbps
- Maximum Distance: 100m (328.08ft)
- IR Support: 20-60 KHz
- Serial Interface: RS-232
- Transmission Protocol: IP
- Transmission Medium: Cat.6
- Special Features: PoE
- Bi-directional Ports: 1 x RS-232 (3-pin terminal block), 6-Pin Phoenix Connector
- Power: 5.5/2.1mm
Physical Properties
- Dimensions (approx.) WxDxH: 204x98.5x21.5mm (8.03x3.88x0.85in)
- Housing Material: Metal
- Net Weight: 0.74kg (1.63lb)
- Operating Temperature: 0°C - 40°C (32°F - 104°F)
- Storage Temperature: -20°C - 60°C (-4°F - 140°F)
- Humidity: 20 - 90% RH (non-condensing)
- Power Requirements: 12VDC 1A
- Colour: Black
