EU Product - Mst Hub Usb Typ C 3.2 Gen 1 DisplayPort 1.4 Triple Monitor 4K60Hz mit DSC 1 - Cable - Digital
Introduction
CSV-1550 - The Club-3D USB Type C 3.2 Gen 1 Multi Stream Transport(MST)Hub DisplayPort™ 1.4 Triple Monitor 4K60Hz with DSC 1.2 is an integrated solution that allow you to enjoy displaying content onto three different monitors / displays simultaneously under MST mode. The three screens can accommodate displaying different contents in parallel or by simply extending the existing screen, giving a panoramic view of the content which maximizes the user’s visual experience. With its multi-display capabilities, this hub can serve as a convenient and hassle-free portable, alternative solution to the conventional docking station.
It’s the perfect solution for host devices which feature DP1.2 /1.4 graphic cards that supports all DP Alt mode video signal output, for gaming and commercial applications. The MST Hub is directly powered from the host thru the USB Type C 3.2 Gen 1 connector.
Specifications
| Ports & interfaces | |
|---|---|
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| DisplayPorts quantity | 3 |
| Microphone in | No |
| Connectivity technology | Wired |
| DisplayPort version | 1.4 |
| Network | |
| Ethernet LAN | No |
| Performance | |
| Maximum digital resolution | 7680 x 4320 pixels |
| Number of displays supported | 3 |
| Country of origin | China |
| Product colour | Black |
| Card reader integrated | No |
| Plug and Play | Yes |
| Certification | FCC, CE EMI |
| Maximum refresh rate | 60 Hz |
| High Dynamic Range (HDR) supported | Yes |
| Technical details | |
| Product colour | Black |
| Plug and Play | Yes |
| Cable length | 0.13 m |
| Harmonized System (HS) code | 84733020 |
| Plastic packaging weight | 5 g |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
| Graphics | |
| Maximum resolution | 7680 x 4320 pixels |
| Storage | |
| Card reader integrated | No |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Weight & dimensions | |
| Weight | 58 g |
| Width | 79 mm |
| Depth | 79 mm |
| Height | 17 mm |
| Package weight | 87 g |
| Package width | 145 mm |
| Package depth | 145 mm |
| Package height | 45 mm |
| Design | |
| Country of origin | China |
| Product colour | Black |
| Certification | FCC, CE EMI |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package weight | 87 g |
| Package width | 145 mm |
| Package depth | 145 mm |
| Package height | 45 mm |
| Packaging content | |
| Manual | Yes |
| Quantity per pack | 1 pc(s) |
| Certificates | |
| Certification | FCC, CE EMI |
| Packaging composition | |
| Plastic packaging weight | 5 g |
| Paper/cardboard packaging weight | 46 g |
| Total plastic packaging weight | 0 g |
| Total paper/cardboard packaging weight | 0 g |
| Logistics data | |
| Harmonized System (HS) code | 84733020 |
| Other features | |
| Cable length | 0.13 m |
