Docking Station USB3.0 - DVI / Hdmi / Audio / Ethernet / 6 USB 3.0 And USB 2.0
Introduction
The universal docking station features HDMI and DVI monitor outputs that can be used to expand or mirror your desktop for the ultimate in productivity. Both HDMI and DVI outputs support video resolution up to 2048x1152 for a stunning display no matter what's on screen. The UDDS-1 from V7 adds DVI, HDMI, Audio, Ethernet, and 6 total additional USB 3.0 and USB 2.0 ports to almost any computer, all from a single device with a space saving vertical stand.
- Dual monitor support with resolution up to 2048x1152 with HDMI, DVI-E, and VGA output
- Total 6 USB Ports - 2 USB 3.0 / 4 USB 2.0 Ports
- Vertical stand to maximize desktop space
Specifications
| Connectivity technology | Docking |
| USB 2.0 ports quantity | 4 |
| Host interface | USB 3.0 (3.1 Gen 1) Type-A |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| DC-in jack | Yes |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Card reader integrated | No |
| Brand compatibility | Universal |
| Maximum digital resolution | 2048 x 1152 pixels |
| Colour of product | Grey |
| RoHS compliance | Yes |
| Certification | CE, FCC |
| Width | 18.8 cm |
| Depth | 7.69 cm |
| Height | 3.1 cm |
| Weight | 599 g |
| Package width | 20.5 cm |
| Package depth | 12.9 cm |
| Package height | 10.5 cm |
| Cables included | DC, USB |
| User guide | Yes |
