EU Product - 60m USB 1.1 Cat.6 Extender Basic
Introduction
The Lindy Cat.6 USB Extender can be used to extend the distance between a USB device and a host computer by up to 60m. It consists of a local unit, which can be connected to the computer or laptop and a remote unit which connects to USB devices like mice or keyboards, perfect for long distance access.
Standard, low cost Cat.5e/6 cable (not included) is used to connect the two units together. For best performance and compatibility, we recommend the use of solid core patched cables.
Specifications
| Performance | |
|---|---|
| Type | Network transmitter & receiver |
| Maximum transfer distance | 60 m |
| Data transfer rate | 12 Mbit/s |
| Cable types supported | Cat5e, Cat6 |
| Design | |
| Housing material | Plastic |
| Certification | CE, FCC, RoHS & REACH, CP65 |
| Product colour | Black |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -20 - 80 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Weight & dimensions | |
| Transmitter width | 5.3 cm |
| Transmitter depth | 2.6 cm |
| Transmitter height | 2 cm |
| Receiver width | 5.3 cm |
| Receiver depth | 2.6 cm |
| Receiver height | 2 cm |
| Weight | 54 g |
| Packaging data | |
| Package width | 180 mm |
| Package depth | 105 mm |
| Package height | 30 mm |
| Package weight | 113 g |
| Technical details | |
| Type | Network transmitter & receiver |
| Maximum transfer distance | 60 m |
| Data transfer rate | 12 Mbit/s |
| Cable types supported | Cat5e, Cat6 |
| Colour | |
| Product colour | Black |
| Certificates | |
| Certification | CE, FCC, RoHS & REACH, CP65 |
