EU Product - BPE144VL2U01 Batterieerweiterungsmodul
Introduction
CyberPower BPE144VL2U01 is an Extended Battery Module (EBM) which can be used in conjunction with compatible UPS systems to provide prolonged system runtime during power interruption. The battery module comes with DC plug-and-play power connectors to allow for adding multiple EBMs. With the built-in charger design, the EBMs can charge directly from utility without resorting to UPS, significantly saving total charging time when charging multiple EBMs.
The product features hot-swappable battery packs, allowing users to safely replace battery module without interrupting connected loads. The sealed lead-acid battery used within the EBM is stable and safe, which ensures the power system's reliable performance. Designed with industrial-grade metal enclosure, the product is suitable for data center and critical applications.
Specifications
| Design | |
|---|---|
| Form factor | Rackmount/Tower |
| Rack mounting | Yes |
| Product colour | Silver |
| Housing material | Metal |
| Compatible products | OL5KERTHD, OL6KERTHD |
| Rack capacity | 2U |
| Brand compatibility | CyberPower |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Number of batteries supported | 12 |
| Battery capacity | 9 Ah |
| Battery voltage | 12 V |
| Hot-swap battery | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 45 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15000 m |
| Weight & dimensions | |
| Width | 433 mm |
| Depth | 720 mm |
| Height | 86.5 mm |
| Weight | 44 kg |
| Package width | 600 mm |
| Package depth | 1100 mm |
| Package height | 335 mm |
| Package weight | 53.1 kg |
| Packaging content | |
| Rack mount kit | Yes |
| Technical details | |
| Sustainability compliance | Yes |
| Sustainability certificates | BSMI, CE, EAC, RCM, RoHS |
| Compliance certificates | BSMI, CE, EAC, RCM, RoHS |
