EU Product - Cat6a 10G STP Keystone-Modul weiß
Introduction
The Cat6a 10G Shielded Toolless Slim Keystone Jack, Black from Intellinet Network Solutions is designed for quick, seamless side-by-side deployment. Without any special tools, this module easily snaps into blank patch panels, wall plates or surface connection boxes. It is suitable for solid conductor cables in high-performance network applications up to 10GBase-T and PoE applications up to IEEE802.3bt / PoE++ / 4PPoE / Ultra PoE. For maximum signal integrity, it is equipped with gold-plated contacts and 360° STP shielding.
Specifications
| Features | |
|---|---|
| Construction type | Flat |
| Product colour | Stainless steel, White |
| Connector 1 | RJ-45 |
| Connector 1 gender | Female |
| Cabling technology | 10GBase-T |
| Connector contacts plating | Gold |
| Cable types supported | Cat6a |
| Housing material | Zinc |
| Plug/connector retention force | 30 N |
| Frequency | 500 MHz |
| Networking standards | IEEE 802.3bt |
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 60 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Technical details | |
| Compliance certificates | CE, REACH, RoHS, UKCA |
| Weight & dimensions | |
| Width | 14.8 mm |
| Depth | 36 mm |
| Height | 20 mm |
| Weight | 10 g |
| Packaging data | |
| Package weight | 20 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
