Specifications
| Technical details | |
|---|---|
| International Protection (IP) code | IP65 |
| Door station control | Yes |
| Wall mountable | Yes |
| Voice codecs | G.711a, G.711u, PCM |
| Streaming capability | Yes |
| Built-in speaker(s) | Yes |
| Built-in microphone | Yes |
| IK code | IK07 |
| Memory card slot | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
| Speakerphone | Yes |
| Connectivity technology | Wired |
| Display | |
| Wide Dynamic Range (WDR) | Yes |
| Camera | |
| Viewing angle, vertical | 87.1° |
| Viewing angle, horizontal | 168.6° |
| Megapixel (approx.) | 2 MP |
| Maximum frame rate | 25 fps |
| Maximum video resolution | 1920 x 1080 pixels |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.9 mm (1 / 2.9") |
| Supported video modes | 720p, 1080p |
| Viewing angle, diagonal | 176.7° |
| Day/night mode | Yes |
| Night vision | |
| Night vision | Yes |
| LED type | IR |
| Audio | |
| Voice codecs | G.711a, G.711u, PCM |
| Built-in speaker(s) | Yes |
| Design | |
| International Protection (IP) code | IP65 |
| IK code | IK07 |
| Product colour | Silver |
| Placement supported | Vertical |
| Housing material | Aluminium |
| Control type | Buttons |
| Storage | |
| Memory card slot | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
| Outdoor unit | |
| RS-485 ports (transmitter) | 1 |
| Power consumption (transmitter) (max) | 5 W |
| Network | |
| Power over Ethernet (PoE) | Yes |
| Supported network protocols | IPv4; RTSP; UDP; DNS; P2P; UPnP; RTP; TCP; SIP |
| Software | |
| Operating system installed | Embedded LINUX |
| Management features | |
| Web-based management | Yes |
| Power | |
| AC adapter output voltage | 48 V |
| AC adapter output current | 1 A |
| Outdoor unit power type | DC/PoE |
| Power consumption (transmitter) (max) | 5 W |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 100 mm |
| Depth | 49.4 mm |
| Height | 100 mm |
| Weight | 430 g |
| Packaging data | |
| Indoor unit included | No |
| Outdoor unit included | Yes |
