Specifications
| Technical details | |
|---|---|
| International Protection (IP) code | IP65 |
| Door station control | Yes |
| Wall mountable | Yes |
| VoIP protocols | RTSP, DNS, P2P, UPnP, RTP, RTMP, SIP, SSH, HTTP/HTTPS, ONVIF |
| Voice codecs | G.711a, G.711u, PCM |
| Built-in speaker(s) | Yes |
| Built-in microphone | Yes |
| IK code | IK08 |
| Motion detection function | Yes |
| Automatic gain control | Yes |
| Display diagonal | 10.9 cm (4.3") |
| Colour | No |
| Speakerphone | Yes |
| Maximum number of cameras supported | 1 |
| Noise-canceling | Yes |
| Connectivity technology | Wired |
| Fingerprint reader | Yes |
| RFID reader | Yes |
| Sustainability compliance | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Display | |
| Display technology | LCD |
| Display resolution | 800 x 480 pixels |
| Video formats supported | H.264 |
| Touchscreen | No |
| Display diagonal | 10.9 cm (4.3") |
| Camera | |
| Viewing angle, vertical | 46.2° |
| Viewing angle, horizontal | 86.4° |
| Megapixel (approx.) | 2 MP |
| Maximum frame rate | 30 fps |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Supported video modes | 720p, 1080p |
| Audio | |
| Voice codecs | G.711a, G.711u, PCM |
| Built-in speaker(s) | Yes |
| Noise-canceling | Yes |
| Design | |
| International Protection (IP) code | IP65 |
| Proper use | Outdoor |
| IK code | IK08 |
| Product colour | Stainless steel |
| Placement supported | Vertical |
| Housing material | Stainless steel |
| Control type | Buttons |
| Network | |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Cabling technology | 10/100Base-T(X) |
| Power over Ethernet (PoE) | Yes |
| Supported network protocols | RTSP, DNS, P2P, UPnP, RTP, RTMP, SIP, SSH, HTTP/HTTPS, ONVIF |
| Software | |
| Operating system installed | Linux |
| Power | |
| Power consumption | 200 mA |
| Power consumption (standby) | 5 W |
| Power consumption (typical) | 18 W |
| AC adapter output voltage | 12 V |
| AC adapter output current | 2 A |
| Outdoor unit power type | DC |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 143 mm |
| Depth | 54 mm |
| Height | 406 mm |
| Packaging data | |
| Package weight | 2.05 kg |
| Outdoor unit included | Yes |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
| Minimum order quantity | 1 pc(s) |
